Description



ABB’s PowerValue 11T G2 is a single-phase in/out, double conversion online uninterruptible power supply (UPS) that guarantees up to 10 kW per single UPS of clean, reliable power for your critical single-phase applications. As well as maintaining power to your server room, advertising display, turnstiles, lab equipment, transportation signaling systems, ATM or vending machine, the PowerValue 11T G2 also conditions incoming power to eliminate spikes, swells, sags, noise and harmonics.

Featuring voltage and frequency independent (VFI) topology, the tower-only PowerValue 11T G2 saves costs by minimizing energy losses with its double conversion efficiency of up to 95 percent (up to 98% in ECO mode). Two or three units can be connected in parallel to boost power delivery to a maximum of 30 kW or to provide redundancy.

Simple to install or maintain, inexpensive to run and with the most compact online UPS footprint available on the market, the PowerValue 11T G2 provides stable, regulated, transient-free, pure sine wave AC power with extremely tight output voltage regulation. All units can be fitted with up to four external battery modules (EBMs) to extend runtime to well over two hours. Each EBM is dedicated to its corresponding UPS and setup is easily accomplished via the LCD menu.

Technical specifications



GENERAL DATA G2 1kVA B
Output rated power 900 W
Output power factor 0.9
Topology Online double conversion
Parallel configuration No
Inbuilt batteries Yes/No

INPUT
Nominal input voltage 220/230/240 VAC
Input voltage tolerance 100-300 VAC (load dependent)
Input current THDi 5% with full resistive load
Frequency range 45-55 Hz / 54-66 Hz
Power factor ≥0.99

OUTPUT
Rated output voltage 220/230/240 VAC
Voltage tolerance ±1% (referred to 230V
Voltage distortion <2% linear load, <6% non linear load
Overload capacity (linear
load) on inverter
60s: 106-130% load
10s: 131-150% load
300ms: ≥ 150% load
Nominal frequency 50 or 60 Hz
Crest factor 3:1 (load supported)

EFFICIENCY
Overall system efficiency Up to 89%
In eco-mode Up to 97.5%
Protection rating IP20
Storage temperature UPS: -25°C to 60°C; Batteries: 0°C to 35°C
Relative humidity 0% to 95%
Altitude (above see level) 1000m without derating

BATTERIES
Type VRLA (valve regulated lead-acid)
Inbuilt batteries 2×9.4 Ah (B)
Charging current 1.5A/3-6A
adjustable
Recharge time (inbuilt batteries) 4h to 90%

COMMUNICATIONS
User interface LCD display
Optional communication cards SNMP;ModBus;AS400;Environmental monitoring sensor probe
STANDARDS
Safety IEC/EN 62040-1
EMC IEC/EN 62040-2
Performance IEC/EN 62040-3
Manufacturing ISO 9001:2015, ISO 14001:2015, OHSAS 18001
WEIGHT, DIMENSIONS Weight 9.2/3.9 Kg
Dimensions w x h x d 144x228x356 mm
102x228x346mm

Warranty *2yrs warranty on parts and service
