Description
APC Smart-UPS On-Line, 15kVA/15kW, Rack/Tower, 230V/380V…415V, Hard wire 5-wire(3P+N+E)+3-wire(1P+N+E), Network Card, W/O rail kit
(SRTG15KXLI)
PC Smart-UPS On-Line, 15kVA/15kW, Rack/Tower, 230V/380V…415V, Hard wire 5-wire(3P+N+E)+3-wire(1P+N+E), Network Card, W/O rail kit
High-density, double-conversion on-line power protection with scalable runtime
Includes: Smart UPS signaling RS-232 cable
Smart-UPS On-Line Features & Benefits
Serviceability
Predictive failure notification.
Provides early-warning fault analysis ensuring proactive component replacement.
User-replaceable batteries
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Audible alarms
Provides notification of changing utility power and UPS power conditions
Automatic self-test
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Disconnected battery notification
Warns when a battery is not available to provide backup power.
Marketing Features
Save time with easy and convenient remote/network accessibility.
Network manageable via serial, USB or Ethernet. Includes Powerchute® Software for convenient monitoring and control, safe operating system shutdown, and innovative energy management capabilities.
Avoids costly power problems by keeping your IT equipment and data protected and available.
Network-grade power conditioning protects from damaging surges and disruptive noise. The double conversion architecture provides tight voltage regulation, frequency regulation, and zero transfer time to the battery during power events.
Low operating and maintenance costs with proven reliability and intelligent battery management .
Intelligent battery management, pioneered by APC, maximizes battery performance and life through intelligent, precision temperature-compensated charging. Automatic self-tests insure battery reliability and warn customers in advance of battery replacement. Convenient, easy-to-connect, hot-swappable battery modules provide battery replacement without powering down.
Peace of mind that comes with full equipment compatibility and reliability of a leader
Provides pure sine wave output which is recommended by server manufacturers using active power factor corrected (PFC) power supplies. Safety agency tested and approved means that you can deploy Smart-UPS with confidence that they meet or exceed the industry’s most rigorous standards.
Protection
Power conditioning
Protects connected loads from surges, spikes, lightning, and other power disturbances.
Resettable circuit breaker
Easy recovery from overloads; no need to replace a fuse. (Not available on Wall Tap SKUs)
Input power factor correction
Minimizes installation costs by enabling the use of smaller generators and cabling.
Cold-start capable
Provides temporary battery power when the utility power is out.
Frequency and voltage regulation
Gives higher application availability by correcting poor frequency and voltage conditions without using the battery.
Generator compatible
Ensures clean, uninterrupted power to protected equipment when generator power is used.
Safety-agency approved
Ensures the product has been tested and approved to work safely with the connected service provider equipment and within the specified environment.
Availability
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.
Scalable runtime
Allows additional run time to be quickly added as needed.
Temperature-compensated battery charging
Prolongs battery life by regulating the charge voltage according to battery temperature.
Automatic internal bypass
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Automatic restart of loads after UPS shutdown
Automatically starts up the connected equipment upon the return of utility power.
Hot-swappable batteries
Ensures clean, uninterrupted power to protected equipment while batteries are being replaced
Manageability
InfraStruXure Manager Compatible
Enables centralized management via the APC InfraStruXure Manager.
Network manageable
Most models provide remote power management options of the UPS over the network. Many do not have NMC embedded.
Serial connectivity
Provides management of the UPS via a serial port.
Intelligent Card Slot Customize UPS capabilities with management cards
LED status indicators Quickly understand unit and power status with visual indicators.
Adaptability
Rack/Tower convertible
Protects the initial investment in the UPS when migrating from tower to rack-mount environment.
Flash upgradeable firmware
Install maintenance releases of firmware remotely using FTP.
Plug-and-Play external batteries
Ensures clean, uninterrupted power to the loads when adding extra runtime to the UPS.
Technical Specifications
Output
Max Configurable Power (Watts) 15.0kWatts / 15.0kVA
Output Voltage Note Configurable for 380 : 400 or 415 V 3 Phase nominal output voltage
Output Voltage Distortion Less than 5 %
Output Frequency (sync to mains) 50/60 Hz +/- 0.1 Hz Sync to mains
Other Output Voltages 230 V
Load Crest Factor 3 : 1
Topology Double conversion online
Waveform type Sine wave
Overload Operation 60 seconds at 125% and 30 seconds at 150%
Bypass Built-in static bypass
Input
Input frequency 40 – 70 Hz Auto-sensing
Input voltage range for main operations 160 – 285, 380V
Input Total Harmonic Distortion Less than 5 % for full load
Other Input Voltages 220, -, 240 V
Batteries & Runtime
Battery type Lead-acid battery
Typical recharge time 4hour(s)
Nominal Battery Voltage +/- 192 V
Replacement Battery
Expected Battery Life (years) 3 – 5
Battery Charge Power (Watts) 2.16kWatts
Extendable Run Time 1
Battery Volt-Amp-Hour Capacity 3366
Efficiency in Battery Operation 93.0 %
Runtime View Runtime Graph
Efficiency View Efficiency Graph
Communications & Management
Emergency Power Off (EPO) Yes
Surge Protection and Filtering
Filtering Full time multi-pole noise filtering : 0.3% IEEE surge let-through : zero clamping response time : meets UL 1449
Physical
Maximum Height 306MM, 30.6CM
Maximum Width 440MM, 44.0CM
Maximum Depth 700MM, 70.0CM
Net Weight 142.5KG
Shipping weight 157.2KG
Shipping Height 535MM, 53.5CM
Shipping Width 790MM, 79.0CM
Shipping Depth 590MM, 59.0CM
Color Black
Environmental
Operating Temperature 0 – 40 °C
Operating Relative Humidity 0 – 95 (Non-condensing) %
Operating Elevation 0 – 3000meters
Storage Temperature -15 – 45 °C
Storage Relative Humidity 0 – 95 (Non-condensing) %
Storage Elevation 0 – 15000meters
Audible noise at 1 meter from surface of unit 58.0dBA
Online thermal dissipation 2866.0BTU/hr
Protection Class IP20
Conformance
Approvals CB
Standard warranty 3 years repair or replace (excluding battery) and 2 years for battery
