Description



Aruba 2930F 24G 4SFP Switch (JL259A)



Performance and ease of use for the enterprise campus, SMB and branch office



Overview:

The Aruba 2930F Switch Series is designed for customers creating digital workplaces that are optimized for mobile users with an integrated wired and wireless approach. These basic Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager and Aruba AirWave. With support from Aruba Central, you can quickly set up remote branch sites with little or no IT support. A powerful Aruba ProVision ASIC delivers performance and value with support of the latest SDN apps with future proof programmability for tomorrow’s applications. Stacking with Virtual Switching Framework (VSF) provides simplicity and scalability. The 2930F supports built-in 1GbE or 10GbE uplinks, PoE+, Access OSPF routing, Tunnel node, robust QoS, RIP routing, and IPv6 with no software licensing required.

The Aruba 2930F Switch Series provides a convenient and cost-effective access switch solution that can be quickly set up with Zero Touch Provisioning and built-in 10GbE uplinks. The robust basic Layer 3 feature set includes a limited lifetime warranty.

Key Features

• Aruba Basic Layer 3 switch series with VSF stacking, static, Rip and Access OSPF Routing, ACLs, and robust QoS
• Consistent wired/wireless experience with Aruba AirWave and Aruba ClearPass Policy Manager
• Convenient built-in 1GbE or 10GbE uplinks and up to 370 W PoE+
• Ready for innovative SDN applications with OpenFlow support
• Simple deployment with Zero Touch Provisioning and cloud-based Aruba Central support



SPECIFICATIONS

I/O ports and slots
24 RJ-45 autosensing 10/100/1000
ports (IEEE 802.3 Type 10BASE-T,
IEEE 802.3u Type 100BASE-TX, IEEE
802.3ab Type 1000BASE-T); Duplex:
10BASE-T/100BASE-TX: half or full;
1000BASE-T:full only
4 SFP+ 1/10GbE ports; PHY-less

Additional ports and slots
1 dual-personality (RJ-45 or USB
micro-B) serial console port

Physical characteristics
Dimensions 17.42 (w) x 7.88 (d) x 1.73 (h) in
(44.25 x 20.02 x 4.39 cm)
(1U height)

Weight 5.31 lb (2.41 kg)

Memory and processor
Dual Core ARM® Coretex A9 @ 1016
MHz, 1 GB DDR3 SDRAM; Packet
buffer size: 12.38 MB 4.5MB
Ingress/7.875MB Egress, 4 GB eMMC



Performance

IPv6 Ready Certified
1,000 Mb Latency < 3.8 μs (64-byte packets)
10 Gbps Latency < 1.6 μs (64-byte packets)
Throughput up to 95.2 Mpps
Switching capacity 128 Gbps
Routing table size 2,000 IPv4, 1,000 IPv6 in hardware,
200 OSPF, 256 Static, 10,000 RIP
MAC address table size 32,768 entries
Environment
Operating temperature 32°F to 113°F (0°C to 45°C); up
to 5,000 Feet, 0°C to 40°C (32°F to
104°F) up to 10,000 Feet
Operating relative
humidity
15% to 95% @ 104°F (40°C),
noncondensing
Non-operating/Storage
temperature
-40°F to 158°F (-40°C to 70°C);
up to 15,000 Feet
Non-operating/Storage
relative humidity
15% to 95% @ 149°F (65°C),
noncondensing
Acoustic Power: 49.7 dB, Pressure: 37.1 dB

Warranty Limited Lifetime
