Description
imageFORMULA DR-M140II
Compact Desktop Scanner for a Productive Workgroup
Made for business, the imageFORMULA DR-M140II helps automate your business’ information capture processes efficiently.
- Desktop Document Scanner
- Scan Size: A4 / LTR
- Scan Speed: Up to 40 ppm (Simplex) / 80 ipm (Duplex)
Features
Compact Space-Saving Design
The U-turn path mode enables full-front operation, while saving space when placed on countertops or tight spaces.
Fast and High-quality Scanning
Scan with an impressive output resolution of up to 1,200 dpi at fast speeds of up to 40 ppm (simplex) / 80 ipm (duplex).
Versatile Media Scanning
DR-M140II is able to handle media of wide ranging textures and thickness. Easy to set-up, fast scanning of paper documents, receipts, IDs and business cards are possible with just a touch of a button.
Scanning
| Type | Desktop Sheet-Fed Scanner |
| Scanning Speed*1 | |
| Greyscale | 200 dpi: 40 ppm (Simplex) / 80 ipm (Duplex) 300 dpi: 40 ppm (Simplex) / 80 ipm (Duplex) |
| Colour | 200 dpi: 40 ppm (Simplex) / 80 ipm (Duplex) 300 dpi: 40 ppm (Simplex) / 80 ipm (Duplex) |
| Scanning Element | Contact Image Sensor (CIS) |
| Light Source | LED |
| Scanning Side | Simplex / Duplex |
| Scanning Modes | Black and White, Error Diffusion, 256-level Greyscale, Active Threshold, Advanced Text Enhancement, Advanced Text Enhancement II, 24-bit Colour |
| Scanner Features | Folio Scanning, Double Feed Release, 2D / Barcode |
| Optical Resolution (Max.) | 600 dpi |
| Output Resolution*2 | 100, 150, 200, 240, 300, 400, 600, 1200 dpi |
Media Handling
| Document Size | |
| Plain Paper | Width: 50.8 to 216 mm Length: 54 to 356 mm (Up to 5,588 mm long with Long Document mode.) |
| Business Card | Width: 50.8 to 55 mm Length: 85 to 91 mm |
| Card (ISO Standard) | 54 x 86 mm |
| Document Thickness and Weight | |
| Plain Paper | U-turn Path: 27 to 128 g/m² (0.04 to 0.15 mm) Straight Path: 27 to 255 g/m² (0.04 to 0.3 mm) |
| Business Card | 380 g/m² (0.45 mm) or smaller (Use the straight path and place vertically.) |
| Card | 0.76 mm or less 1.4 mm or less for the embossment (Use the straight path and place vertically.) |
| ADF Capacity*3 | 80 sheets |
Connectivity & Software
| Interface | USB 2.0 |
| Software | ISIS / TWAIN / WIA Drivers, CaptureOnTouch |
General
| Power Requirements | AC 100 – 240 V (50 / 60 Hz) |
| Power Consumption | |
| Scanning (Max.) | 24.5 W |
| Sleep Mode | 1.6 W |
| With Power Switched OFF (Max.) | 0.1 W |
| Operating Environment | |
| Temperature | 10 to 32.5°C |
| Humidity | 20 to 80% RH |
| Dimensions (W x D x H) | |
| When Trays Are Closed | 313 × 181 × 93 mm |
| When Trays Are Opened | 313 × 250 × 165 mm |
| Weight (Approx.) | 2.6 kg (without AC adapter) |
Consumables & Accessories
| Options / Consumables | Exchange Roller Kit |
| Accessories | Flatbed Scanner Unit 102 Flatbed Scanner Unit 201 |
