Description
Product Description
Features
High efficiency, up to 95% kVA=kW, Output PF=1
3 level of technology, compatible with complicated load
Self-aging function
Intelligent digital charging management,maximum charger current up to 12A
Smaller size with higher power density Parallel up to 8 units
HT11 series, ranging from 6KVA to 10KVA, is double conversion online UPS with fully DSP controlled technology. The single phase UPS applies the advanced 3-level technology, achieving a efficiency up to 95%. With its compact design of high power density (kW=kVA), HT11 series make it ideal choice for computers, telecommunication equipment and other sensitive devices.
MODEL HT1106XS
Capacity 6kVA / 6000W
Display LED + LCD ROTATABLE
INPUT VOLTAGE RANGE 110Vac – 288Vac
100% load @ >178Vac; 90% load @ > 160Vac
80% load @ >140Vac; 60% load @ > 110Vac
Input PF ≥ 0.99
Input frequency 40Hz – 70Hz
Output PF 1
Output voltage 220V / 230V / 240V
Voltage regulation ±1 %
Overload (Inverter) 110% for 10 min; 130% for 1 min 150%: for 30 sec (shut
down the bypass after 1min)
Capability (Battery) 110%: Shutdown after 10 mins; 125% Shutdown after 10s;
>125%: Shutdown after 1s
Crest factor 3:1
Efficiency Normal mode:93%;
ECO mode:98%;
Battery mode:92%
Battery voltage 192Vdc
Battery type/ number 12V, 7Ah *16 (built-in)
Backup time (50%/100%) 7.48mins / 1.38mins
Max. charging current 5A
Interface RS232, EPO (Optional:SNMP, USB, Dry Contactor(AS400),
Parallel Kit, ECO Kit, External Battery Cable(standard model),
Maintenance Bypass, Maintenance Bypass Detecting Kit)
W*D*H (mm) 190*426*705
Package Weight (kg) 56
