Description

48-Port Managed Gigabit PoE+ Switch with 4 10G SFP+ Uplinks 740W TAA Compliant

SKU LGS352MPC

FEATURES

• 1G SFP OR 10G SFP+ UPLINK PORTS

  Enable fast, dedicated connections back to your core network. Our 8-Port switches come with 2x 1G SFP uplinks while our 24/48-port switches come with 4x 10G SFP+ uplinks.

  INTEGRATED POWER OVER ETHERNET PLUS (POE+)

  Makes installation simple and inexpensive by eliminating the need for additional power cables and nearby power outlets. Backwards compatible with 802.3af (PoE) standard.

  NETWORK EXPANSION FEATURES

  Build a mesh of switches easily with features like Spanning Tree Protocol (STP) and storm control. They help control planned or inadvertent cable loops so you can expand your network with confidence.

  ADVANCED NETWORK SECURITY

  Ensure data passes to authorized clients only with port authentication. Advanced DHCP snooping and IP-MAC binding functions assure network integrity and help prevent attacks.

  QUALITY OF SERVICE (QOS) TRAFFIC PRIORITIZATION

  Prioritize traffic with numerous QoS features. Ideal for real-time voice and video applications as well as high bandwidth graphic or video uploads and downloads.

  TAA COMPLIANT FOR GSA SCHEDULE CONTRACTS

  Our switches are manufactured in Taiwan, which is a TAA designated country approved for GSA Schedule Contracts and federal use.

  With Linksys’ new line of smart managed PoE+ switches, you get more total power budget than ever before. That means powering more PoE devices with less switches, driving more value in your network deployment.



  Dedicated Connections Back to the Core

  Use dedicated SFP uplink ports to connect to other switches or back to your core network instead of taking away from one of your existing PoE+ ports. Plus, with our 24 and 48 port switches, you get high speed 10G SFP+ ports to ensure maximum bandwidth capacity for your edge devices.

  Advanced Security, QoS, and Static Routing

  Secure and optimize your smart managed network with advanced security and QoS features. On top of that, we’ve added static routing for free, typically only found in higher end switches.

  ---



  TAA-Compliant

  Our switches are manufactured from a TAA approved country, so you can use them for GSA schedule and federal contracts.



  ---

  How Does It Work?

  Linksys Managed Gigabit PoE+ switches can power PoE+ enabled devices such as surveillance cameras, access points, door access control systems, VoIP phones and ProAV systems. This will eliminate the need for additional power cables and outlets, making installation simpler and less expensive.

  TECHNICAL SPECS

  • Model Name: LGS352MPC
  • Routing: Static Routing, IPv4 (63 max entries), IPv6 (21 max entries)
  • Ports:
    • 48 Gigabit Ethernet
    • 4 10G SFP+
  • Memory: 512MB
  • LEDs: Power, Fault, PoE Max, LAN Mode, PoE Mode
  • Forwarding Rate: 130.95 Mpps
  • Switching Capacity: 176 Gbps
  • MAC Address Table Size: 32K
  • Jumbo Frame (FE, GE): 12Kbytes
  • Fans: 3, 8200 rpm (at full speed)
  • Dimensions (LxWxH):
    • 440 x 410 x 44 mm
    • 17.32 x 16.14 x 1.73 in
  • Weight: 4707 g (10.38 lb)
  • Power Consumption: 885W
  • Power Dedicated to PoE+: 740W
  • Power Input:
    • 100–240V
    • 50–60 Hz
    • 12A
  • Power Saving: EEE
  • Operating Temperature: 0 to 50°C (32 to 122°F)
  • Storage Temperature: -20 to 70°C (-4 to 158°F)
  • Operating Humidity: 10 to 90% RH
  • Storage Humidity: 5 to 95% RH (non-condensing)
  • Spanning Tree:
    IEEE 802.1d Spanning Tree, IEEE 802.1w Rapid Spanning Tree, IEEE 802.1s Multiple Spanning Trees (16 instances) IGMP, MLD

  • Link Aggregation: IEEE 802.3ad LACP, up to 8 groups with up to 8 ports per group
  • VLAN: Port-based and 802.1q VLANs, Management VLAN, Guest VLAN support
  • Number of VLANs Supported: 256 active VLANs (4,096 range)
  • Auto Voice VLAN:
    Voice traffic is automatically assigned by OUI to a voice-specific VLAN and treated with appropriate levels
  • IGMP Snooping:
    IGMP (v1/v2/v3) snooping provides for fast client joins and leaves of multicast streams and limits bandwidth-intensive video traffic to only the requestors; supports 256 multicast groups
  • HOL Blocking Prevention: Head of line (HOL) blocking prevention
  • Port Mirroring:
    Traffic on multiple ports (up to 3 ports) can be mirrored to another port for analysis with a network analyzer
  • Security Features:
    • 802.1x Radius authentication
    • DHCP snooping
    • IP-MAC binding
    • Port Security (256 max entries per port)
  • Storm Control:
    Support broadcast/unknown multicast/unknown unicast 16kbps~1000Mbps: in steps of 16kbps
  • Quality Of Service:
    • 8 hardware queues
    • Strict, Weighted Round Robin (WRR)
    • Port-based, 802.1p priority-based, IPv4/v6 IP DSCP-based
  • Access Control:
    Ingress, MC Based ACL, IPv4 Based ACL, IPv6 Based ACL, ACL Binding, Action: permit/deny
  • RMON:
    Embedded remote monitoring (RMON 1, 2, 3, 9) software agent support for enhanced traffic management, monitoring, and analysis
  • Management Interface:
    • HTTP
    • HTTPS
  • Other Management:
    Telnet, SSH, DHCP client, system log, configuration upload and backup via HTTP or TFTP, PING, Traceroute, dual images, SNTP
  • SNMP:
    • Version 1
    • Version 2c
    • Version 3
  • Firmware Upgrade:
    • Web Browser (HTTP/HTTPS)
    • TFTP
  • Rate Limiting:
    Rate limit according to network speed, 12kbps~1000Mbps: in steps of 16kbps
  • Warranty and Support:
    • 5 Year Warranty (most countries)
