Description
Giant I Series (3P/3P)-Tower
PROLiNK Giant I Series (3P/3P) three-phase output UPS system is designed based on true online double conversion technology and using galvanic isolation transformer design which guarantees to supply consistent and quality electrical power to protect critical applications. The UPS systems accept dual-mains inputs. DSP control technology is implemented for the system to have improved performance and high reliability.
Prolink Giant I Series 3 phase UPS system uses true online double conversion technology with galvanic isolation transformer design which guarantees to supply consistent and quality electrical power to protect your mission critical applications. DSP control technology is implemented for the system to have improved performance and high reliability.
All internal PCBAs are coated to withstand harsh environment.
Users can easily monitor and access to their UPS status from a comprehensive LCD display. The UPS systems have USB and RS-232 communication ports as standard, with a built-in intelligent slot for additional adapters, protocol converters and relay contact cards. SNMP option is also available for power management via SNMP manager and web browser. Giant I (3P/1P) series is available in models ranging from 10kVA to 40kVA and Giant [3P/3P] series is from 10kVA to 200kVA.
In addition, the system comes with a parallel redundant configuration option that allows four units to operate in parallel.
Key Features
- Online double-conversion
- DSP technology guarantees high reliability
- True galvanic isolation transformer design
- Control designed to withstand all kinds of loads
- Intelligent battery management to prolong battery lifecycle
- Redundant fan design and independent ventilation enhance durableoperation under harsh environment
- Adjustable battery numbers
- Accept dual-mains input
- Parallel operation with up to 4 units (option)
- Varieties of communication options available
- Optional 7″ touch LCD
- Reverse phase frequency operation and supports non-neutral input
- Output Isolation Transformer
Electro-Medical Device
PLC Control System
Emergency Alarm Devices
Building Management System
Specifications
GENERAL
| UPS Type | Tower |
| Phase | 3 phase in / 3 phase out |
| Rating (VA) | 60KVA |
| Nominal Power (W) | 48KW |
| Dimension (mm) | 821 x 432 x 1159 (D x W x H) |
| Weight (kg) | 365 |
INPUT
| Connection Type | Terminal |
| Nominal Voltage | 3 x 380VAC / 400VAC / 415VAC (3Ph or 3Ph+N) |
| Acceptable Voltage Range | 285VAC ~ 475VAC |
| Frequency | 50/60 Hz ± 10 % |
INVERTER
| Connection Type | Terminal |
| Nominal Voltage | 3 x 380VAC / 400VAC / 415VAC (3Ph+N) (Selectable) |
| Frequency | 50 Hz |
| Max. Synchronization Speed | ±1 Hz/s |
| Admissible Crest Factor | 3:1 |
| Harmonic Distortion | <2% (Linear Load)<5% (Non-linear Load) |
STATIC BYPASS
| Type | Solid state |
| Voltage | 3 x 380VAC/400VAC/415VAC (3Ph+N) |
| Admissible Overload | 150% for 1 hour; 180% for 30sec; >200% for 200ms |
| Transfer to Bypass | Immediate, for overloads above 160% |
BATTERY
| Battery Type and Numbers | 12VDC x 32 pcs (29~32 pcs adjustable) |
| Nominal Battery Voltage | 384 VDC (Based on 32pcs batteries) |
| Charging Method | CC/CV |
| Precision | ±1% |
| Charging Current | Default: 10A. Max. 40A |
| Charging Voltage | 432 VDC (Based on 32pcs batteries) |
- Warranty : 2 years parts and service
: 1 year on battery
